Concrete Mixer Truck Bearing CPM 2513 CPM2513

Product Details:

Place of Origin:	Germany
Model Number:	CPM 2513 CPM2513

Payment & Shipping Terms:

Minimum Order Quantity:	1
Packaging Details:	Carton Box
Delivery Time:	1 day upon your payment
Payment Terms:	PayPal , Western Union, T/T, MoneyGram

Contact Now

Detailed Product Description

Concrete Mixer Truck Reducer Bearing CPM2513 have two spherical rollers, the outer ring raceway is in spherical shape. This bearing has a function of automatic self-aligning, so can compensate the error caused by the axial deformation or housing units. The roller and raceway of the Concrete Mixer Truck Reducer Bearing CPM2513 are for line contact, then the bearing can stand a bigger radial load and axial load.

Item NO.	ID	OD	Width	Weight(kg)
CPM2513	200	300	70.12/118	20
40779	200	300	70.12/118	20
PLC110/190	110	190	-	8
8H312	110	190	-	8
540626AA	100	150	61/50	3.5
800730	100	160	66/61	4
400365	100	160	66/61	4
BS2B 248180	100	165	65/52	5
809280	100	165	65/52	5
11449	100	180	82/69	8
PLC59-5	100	180	82/69	8
801806	110	180	82/74	8
400903	110	180	82/74	8
534176	110	180	82/69	8
PLC59-10	110	180	82/69	8
804312A	120	215	80/58	10
809281	120	215	98/76	14
801215A	100	160	66/61	4
579905AA	110	180	82/74	8
579905A	110	180	82/69	8
H4832	100	165	65/52	5
TX1010	200	300	70.126	-
BS2-3046	120	215	80/58	10
801804
295493

4.Concrete mixer truck bearing model list

Designation	Dimension (mm)
Designation	d	D	B/B1
40779	200	300	70.12/118
PLC110/190	110	190
CPM2513	200	300	70.12/118
8H312	110	190
540626AA	100	150	61/50
800730	100	160	66/61
400365	100	160	66/61
BS2B 248180	100	165	65/52
809280	100	165	65/52
11449	100	180	82/69
PLC59-5	100	180	82/69
801806	110	180	82/74
400903	110	180	82/74
534176	110	180	82/69
PLC59-10	110	180	82/69
804312A	120	215	80/58
809281	120	215	98/76

Bearings For Cement Mixer Gearboxes	d	D	B
mm	mm	mm
534176	110	180	69/82
801806	110	180	74/82
800730	100	160	61/66
B09280	100	165	52/65
11449	100	180	69/82
PLC110/190	110	190	79/82
540626AA.J30CNF	100	150	50/62
2513D11	200	300	118
804312A	120	215	58/80
804182	110	180	69/82
400365	100	160	61/66
PLC59-5	100	180	69/82
PLC59-10	110	180	69/82
PLC58-6	100	150	50/62
F-809280.PRL	100	165	52/65
F-800730.PRL	100	160	61/66
F-801806.PRL	110	180	74/82
F-804312.PRL	120	215	58/80
Z-534176.PRL	110	180	69/82
F-809281.PRL	120	215	76/9B
801216A	100	180	69/82
579905AA	110	180	74JB2
579905A	110	180	69/82
809281	120	215	76/98
8H312	110	190	79/02
40779	200	300	118
2P22O6	110	180	82
601805	110	180	69
PLC510-23	120	215	76/98
BS2-3046	120	215	58/80
BS2B248180	100	165	52/65
722361018	200	300	118
801215A	100	160	61/66
582308
575869
23224X3
